FSFG High Square Plansifter

Type:FSFG6×16Number of Plaid:15-18Squire of sieve(㎡):30.2Power:Y132S-6(3.0kw)Size (mm):2510×2500×1940

We're here to help: Easy ways to get the answers you need. Get Price

Share with :


FSFG High Square Plansifter
FSFG High Square Plansifter is one of the important equipment in grain flour production industry. It is mainly used for sifting and grading materials after grinding. It is able to finish grading materials based on particle size, and sifting flour from ground materials, which can reduce latter working load of other grain flour processing machines and energy cost, increase produciton and grinding rate. It can be used with diamond brand BS model flour mill.

FSFG High Square Plansifter Features
1. All steel plates are made by high quality steel plate.
2. All plates adopt laser cutting machine.
3. Bending and welding adopt numerical control bender and argon arc welding.
4. The suspender of highquire plansifter adopts glass fiber reinforced plastics suspender.
5. Screen frame and surface grid adopt aluminium alloy material, and its accuracy is high and will not be distorted.
6. All steel should be carried on parkerising and shot blasting treatment, then spray paint or baking finish.
7. High-quality clean and quickly to push materials.

high square plansiftergrain flour

FSFG High Square Plansifter Technical Parameter
Type Number of Plaid Squire of sieve(m2) Power Size (mm)
FSFG6×16 15-18 30.2 Y132S-6(3.0kw) 2510×2500×1940
FSFG6×24 22-24 52 Y112M-6(5.5kw) 2510×1640×2440
FSFG8×24 22-24 76 Y112M-6(7.5kw) 3380×2480×3740
